Capsule Filling Machine NJP-2-400C

SKU:NJP-2-400C
Description:

Model Number: NJP-2- 400C
Capacity: 400 capsule/min
Suitable for capsule: 00#~4#
Total Power :3 kw
Overall Weight:700 KG
Overall Dimension: 700mm*800mm*1700mm

Make an Inquiry Now

Product Details
Specification Sheet
Usages
MSDS
Make an Inquiry

Working steady, safe and reliable enough
Capsule qualified rate is 99%
Capsule:00#~4#
Accord to GMP standard
Easy to operate

Main Technical ParameterOutput400 capsule/minNo. of segment bores3Suitable for capsule00#~4#Total Power3 kwOverall Weight700 KGOverall Dimension700×800×1700MM

Machinery Characters1.Working steady, safe and reliable enough.2.Capsule qualified rate is ≥99% with the precise dosage.3.Timing frequency-conversion, programmable controlled.4.New closed structure, accord to GMP standard.

StateNJP-2-400 Fully Automatic Capsule Filling Machine is filled by powder,grain,tablet, It adopts multi-bore dosing,intermittent motion and timing frequency conversion.It is suitable for automatically completing capsule feeding,separating,filling,(waste capsule rejecting),closing,finished product ejecting for powder or tiny pill medicine in capsule. It is designed sophisticatedly by our factory according to the practice on domestic, it is fully accord with the GMP standard.It is so welcomed by the Medicine Graduate School,hospital,small-scale medicine made factories and clinics upon occupying the market.Meanwhile,this type machine replaced of the Semi automatic capsule filling machine and won a good reputation with our reliable quality and reasonable price in domestic and aboard.

Main Features·It has been improved the inner design turret,and imports beeline bearings for each machine from Japan directly,so that it can be sure a longer usage-life and precision of machine.·The working station cam runs under the good lubricating condition,and maintains the inner lubrication of cam slot to a full extent,increasing the pressure pulverization oil pump,thus extends the operation life of the spare parts.·It is controlled by the computer, has a stepless timing with the frequency-conversion, the numeral showing makes an easy operation and clear appearance.·The multi-bore dosing brings a precision dosage (it is controlled around ±3.5%); the good capsule applicability makes a higher capsule qualified rate (>99%).It can be filled with the Chinese traditional medicine and the Western medicine.·It has a protector equipment for the operator and the machine.It has a automatic pause equipment when it is lack for the material.It has a steady and safe working, it is the best choice for the hard capsule made factories.
